Kukko 21-89 3-shell Internal extractor For extracting inner bearings, bearing outer rings and bushings.   Description The 2-shell design with extra large grasp edges ensures safe extraction. The internal extractors are equipped with an internal safety stop to protect against excess spreading and overloading. Mechanical pressure screw. Advantage KUKKO internal extractors can be combined with counter supports and slide hammers. When combined with the internal extractors, extensions from series 21-V enable deeper bearings to be extracted. Spare parts are available for internal extractor sizes 21-89 and 21-90. KUKKO quality standards Quality made in Germany. Strong design, high performance and long service life. Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI). Safety label to ensure protection of intellectual property.   Series 21 Item no. EAN 4021176 Ball-bearing ISO Inner diameter of the ball bearing mm Inner diameter of the ball bearing inch Operating depth mm Operating depth inch Length of the internal extractor mm Length of the internal extractor inch Number of segments Weight kg 21-0 010408 625; 635; 626; 607; 627; 608; 619/8; 628/8 5 - 8 1/4 - 3/8 14 5/8 73 2 7/8 2 0.115 21-00 010576 626; 607; 627; 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300 6 - 10 1/4 - 3/8 14 5/8 73 2 7/8 2 0.12 21-01 010651 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 8 - 12 3/8 - 3/16 14 5/8 73 2 7/8 2 0.115 21-02 010736 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 10 - 14 3/8 - 5/8 14 5/8 73 2 7/8 2 0.115 21-1 010811 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301; 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902 12 - 16 3/16 - 5/8 25 1 72 2 7/8 2 0.16 21-2 010996 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902; 6003; 6203; 6303; 6403; 6803; 6903; 16003; 61803; 61903 14 - 19 5/8 - 3/4 27 1 1/16 72 2 7/8 2 0.12 21-3 011153 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904 18 - 23 3/4 - 7/8 35 1 3/8 89 3 1/2 2 0.2 21-4 011238 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904; 6005; 6205; 6305; 6405; 6805; 6905; 16005; 61805; 61905; 6006; 6206; 6306; 6406; 16006; 61806; 61906 20 - 30 3/4 - 1 3/16 40 1 5/8 92 3 5/8 2 0.235 21-5 011498 6006; 6206; 6306; 6406; 16006; 61806; 61906; 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908 28 - 40 1 3/16 - 1 5/8 30 1 3/8 101 4 2 0.395 21-6 011566 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908; 6009; 6209; 6309; 6409; 16009; 61809; 61909 35 - 46 1 3/8 - 1 7/8 50 2 113 4 3/8 2 0.68 21-7 011641 6009; 6209; 6309; 6409; 16009; 61809; 61909; 6010; 6210; 6310; 6410; 16010; 61810; 61910; 6011; 6211; 6311; 6411; 16011; 61811; 61911 45 - 58 1 3/4 - 2 1/4 85 3 3/8 135 5 3/8 2 1.23 21-8 011726 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014 56 - 70 2 1/4 - 2 3/4 85 3 3/8 133 5 1/4 2 1.43 21-9 011986 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320; 16020; 61820 70 - 100 2 3/4 - 3 7/8 95 3 3/4 166 6 1/2 2 2.9 21-89 011801 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320 56 - 110 2 1/4 - 4 3/8 120 4 3/4 187 7 3/8 3 2.4 21-90 012068 6020; 6220; 6320; 16020; 61820; 6022; 6222; 6322; 16022; 61822; 6024; 6224; 16024; 61824; 6026; 6226; 61826; 6028; 6228; 61828; 6030; 61830; 6032; 61832; 6034; 61834; 6036; 61838; 6040; 61840 100 - 200 3 7/8 - 7 7/8 175 6 7/8 220 8 5/8 3 6.58

Kukko 21-9 Internal extractor For extracting inner bearings, bearing outer rings and bushings.   Description The 2-shell design with extra large grasp edges ensures safe extraction. The internal extractors are equipped with an internal safety stop to protect against excess spreading and overloading. Mechanical pressure screw. Advantage KUKKO internal extractors can be combined with counter supports and slide hammers. When combined with the internal extractors, extensions from series 21-V enable deeper bearings to be extracted. Spare parts are available for internal extractor sizes 21-89 and 21-90. KUKKO quality standards Quality made in Germany. Strong design, high performance and long service life. Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI). Safety label to ensure protection of intellectual property.   Series 21 Item no. EAN 4021176 Ball-bearing ISO Inner diameter of the ball bearing mm Inner diameter of the ball bearing inch Operating depth mm Operating depth inch Length of the internal extractor mm Length of the internal extractor inch Number of segments Weight kg 21-0 010408 625; 635; 626; 607; 627; 608; 619/8; 628/8 5 - 8 1/4 - 3/8 14 5/8 73 2 7/8 2 0.115 21-00 010576 626; 607; 627; 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300 6 - 10 1/4 - 3/8 14 5/8 73 2 7/8 2 0.12 21-01 010651 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 8 - 12 3/8 - 3/16 14 5/8 73 2 7/8 2 0.115 21-02 010736 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 10 - 14 3/8 - 5/8 14 5/8 73 2 7/8 2 0.115 21-1 010811 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301; 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902 12 - 16 3/16 - 5/8 25 1 72 2 7/8 2 0.16 21-2 010996 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902; 6003; 6203; 6303; 6403; 6803; 6903; 16003; 61803; 61903 14 - 19 5/8 - 3/4 27 1 1/16 72 2 7/8 2 0.12 21-3 011153 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904 18 - 23 3/4 - 7/8 35 1 3/8 89 3 1/2 2 0.2 21-4 011238 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904; 6005; 6205; 6305; 6405; 6805; 6905; 16005; 61805; 61905; 6006; 6206; 6306; 6406; 16006; 61806; 61906 20 - 30 3/4 - 1 3/16 40 1 5/8 92 3 5/8 2 0.235 21-5 011498 6006; 6206; 6306; 6406; 16006; 61806; 61906; 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908 28 - 40 1 3/16 - 1 5/8 30 1 3/8 101 4 2 0.395 21-6 011566 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908; 6009; 6209; 6309; 6409; 16009; 61809; 61909 35 - 46 1 3/8 - 1 7/8 50 2 113 4 3/8 2 0.68 21-7 011641 6009; 6209; 6309; 6409; 16009; 61809; 61909; 6010; 6210; 6310; 6410; 16010; 61810; 61910; 6011; 6211; 6311; 6411; 16011; 61811; 61911 45 - 58 1 3/4 - 2 1/4 85 3 3/8 135 5 3/8 2 1.23 21-8 011726 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014 56 - 70 2 1/4 - 2 3/4 85 3 3/8 133 5 1/4 2 1.43 21-9 011986 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320; 16020; 61820 70 - 100 2 3/4 - 3 7/8 95 3 3/4 166 6 1/2 2 2.9 21-89 011801 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320 56 - 110 2 1/4 - 4 3/8 120 4 3/4 187 7 3/8 3 2.4 21-90 012068 6020; 6220; 6320; 16020; 61820; 6022; 6222; 6322; 16022; 61822; 6024; 6224; 16024; 61824; 6026; 6226; 61826; 6028; 6228; 61828; 6030; 61830; 6032; 61832; 6034; 61834; 6036; 61838; 6040; 61840 100 - 200 3 7/8 - 7 7/8 175 6 7/8 220 8 5/8 3 6.58

Kukko 21-90 3-shell Internal extractor For extracting inner bearings, bearing outer rings and bushings.   Description The 2-shell design with extra large grasp edges ensures safe extraction. The internal extractors are equipped with an internal safety stop to protect against excess spreading and overloading. Mechanical pressure screw. Advantage KUKKO internal extractors can be combined with counter supports and slide hammers. When combined with the internal extractors, extensions from series 21-V enable deeper bearings to be extracted. Spare parts are available for internal extractor sizes 21-89 and 21-90. KUKKO quality standards Quality made in Germany. Strong design, high performance and long service life. Self-healing corrosion protection KUKKoating for galvanized parts (WITHOUT chrom VI). Safety label to ensure protection of intellectual property.   Series 21 Item no. EAN 4021176 Ball-bearing ISO Inner diameter of the ball bearing mm Inner diameter of the ball bearing inch Operating depth mm Operating depth inch Length of the internal extractor mm Length of the internal extractor inch Number of segments Weight kg 21-0 010408 625; 635; 626; 607; 627; 608; 619/8; 628/8 5 - 8 1/4 - 3/8 14 5/8 73 2 7/8 2 0.115 21-00 010576 626; 607; 627; 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300 6 - 10 1/4 - 3/8 14 5/8 73 2 7/8 2 0.12 21-01 010651 608; 619/8; 628/8; 609; 618/9; 629; 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 8 - 12 3/8 - 3/16 14 5/8 73 2 7/8 2 0.115 21-02 010736 6000; 6200; 6300; 6800; 6900; 61800; 61900; 62200; 62300; 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301 10 - 14 3/8 - 5/8 14 5/8 73 2 7/8 2 0.115 21-1 010811 6001; 6201; 6301; 6801; 6901; 16001; 16101; 61801; 61901; 62201; 62301; 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902 12 - 16 3/16 - 5/8 25 1 72 2 7/8 2 0.16 21-2 010996 6002; 6202; 6302; 6802; 6902; 16002; 61802; 61902; 6003; 6203; 6303; 6403; 6803; 6903; 16003; 61803; 61903 14 - 19 5/8 - 3/4 27 1 1/16 72 2 7/8 2 0.12 21-3 011153 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904 18 - 23 3/4 - 7/8 35 1 3/8 89 3 1/2 2 0.2 21-4 011238 6004; 6204; 6304; 6404; 6804; 6904; 16004; 61804; 61904; 6005; 6205; 6305; 6405; 6805; 6905; 16005; 61805; 61905; 6006; 6206; 6306; 6406; 16006; 61806; 61906 20 - 30 3/4 - 1 3/16 40 1 5/8 92 3 5/8 2 0.235 21-5 011498 6006; 6206; 6306; 6406; 16006; 61806; 61906; 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908 28 - 40 1 3/16 - 1 5/8 30 1 3/8 101 4 2 0.395 21-6 011566 6007; 6207; 6307; 6407; 16007; 61807; 61907; 6008; 6208; 6308; 6408; 16008; 61808; 61908; 6009; 6209; 6309; 6409; 16009; 61809; 61909 35 - 46 1 3/8 - 1 7/8 50 2 113 4 3/8 2 0.68 21-7 011641 6009; 6209; 6309; 6409; 16009; 61809; 61909; 6010; 6210; 6310; 6410; 16010; 61810; 61910; 6011; 6211; 6311; 6411; 16011; 61811; 61911 45 - 58 1 3/4 - 2 1/4 85 3 3/8 135 5 3/8 2 1.23 21-8 011726 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014 56 - 70 2 1/4 - 2 3/4 85 3 3/8 133 5 1/4 2 1.43 21-9 011986 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320; 16020; 61820 70 - 100 2 3/4 - 3 7/8 95 3 3/4 166 6 1/2 2 2.9 21-89 011801 6012; 6212; 6312; 6412; 16012; 61812; 61912; 6013; 6213; 6313; 16013; 61913; 6014; 6214; 6314; 16014; 6015; 6215; 6315; 16015; 6016; 6216; 6316; 16016; 61816; 6017; 6217; 6317; 6018; 6218; 6318; 16018; 61818; 6219; 6319; 6020; 6220; 6320 56 - 110 2 1/4 - 4 3/8 120 4 3/4 187 7 3/8 3 2.4 21-90 012068 6020; 6220; 6320; 16020; 61820; 6022; 6222; 6322; 16022; 61822; 6024; 6224; 16024; 61824; 6026; 6226; 61826; 6028; 6228; 61828; 6030; 61830; 6032; 61832; 6034; 61834; 6036; 61838; 6040; 61840 100 - 200 3 7/8 - 7 7/8 175 6 7/8 220 8 5/8 3 6.58

Kukko Extension for internal extractor DescriptionWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted. UseExtensions for internal extractor. AdvantageAlmost all components available as replacement parts, time-saving order process thanks to numbering system. How it worksWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted.For removal, the extensions have to be screwed onto the internal extractors. Safety informationDo not use any electrical or pneumatic servo screwdrivers or hammer drills.Protective blanket required.Protective goggles required.

Kukko Extension for internal extractor DescriptionWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted. UseExtensions for internal extractor. AdvantageAlmost all components available as replacement parts, time-saving order process thanks to numbering system. How it worksWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted.For removal, the extensions have to be screwed onto the internal extractors. Safety informationDo not use any electrical or pneumatic servo screwdrivers or hammer drills.Protective blanket required.Protective goggles required.

Kukko Extension for internal extractor DescriptionWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted. UseExtensions for internal extractor. AdvantageAlmost all components available as replacement parts, time-saving order process thanks to numbering system. How it worksWhen combined with the internal extractors, extensions from series 21 enable deeper bearings to be extracted.For removal, the extensions have to be screwed onto the internal extractors. Safety informationDo not use any electrical or pneumatic servo screwdrivers or hammer drills.Protective blanket required.Protective goggles required.

Kukko 22-1 Counterstay   Description The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3) The counter support nuts' friction resistance is reduced to a minimum as a result of the built-in pressure bearing (size 2 to 5). Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process. Mechanical pressure screw. Use For use with series 21, series 21-E or series 22-1-AS. Advantage The counter support can be combined with internal extractors and Kukko screw adapters. Almost all components available as replacement parts, time-saving order process thanks to numbering system.    Series 22   Art.Nr. EAN 4021176 Spannweite Gegenstütze mm Spannweite Gegenstütze inch Spanntiefe Gegenstütze mm Spanntiefe Gegenstütze inch Max. zulässige Belastung t Gewicht kg 22-1 012228 55 2 3/16 120 4 3/4 3 0.69 22-2 012303 100   165   4 1.873 22-3 012488 180   280   5 4 22-4 112478 200   205   7 4.01 22-5 012556 300   260   9 7.76

Kukko Set of thread inserts

Kukko 22-2 Counterstay   Description The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3) The counter support nuts' friction resistance is reduced to a minimum as a result of the built-in pressure bearing (size 2 to 5). Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process. Mechanical pressure screw. Use For use with series 21, series 21-E or series 22-1-AS. Advantage The counter support can be combined with internal extractors and Kukko screw adapters. Almost all components available as replacement parts, time-saving order process thanks to numbering system.    Series 22   Art.Nr. EAN 4021176 Spannweite Gegenstütze mm Spannweite Gegenstütze inch Spanntiefe Gegenstütze mm Spanntiefe Gegenstütze inch Max. zulässige Belastung t Gewicht kg 22-1 012228 55 2 3/16 120 4 3/4 3 0.69 22-2 012303 100   165   4 1.873 22-3 012488 180   280   5 4 22-4 112478 200   205   7 4.01 22-5 012556 300   260   9 7.76

Kukko 22-3 Counterstay   Description The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3) The counter support nuts' friction resistance is reduced to a minimum as a result of the built-in pressure bearing (size 2 to 5). Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process. Mechanical pressure screw. Use For use with series 21, series 21-E or series 22-1-AS. Advantage The counter support can be combined with internal extractors and Kukko screw adapters. Almost all components available as replacement parts, time-saving order process thanks to numbering system.    Series 22   Art.Nr. EAN 4021176 Spannweite Gegenstütze mm Spannweite Gegenstütze inch Spanntiefe Gegenstütze mm Spanntiefe Gegenstütze inch Max. zulässige Belastung t Gewicht kg 22-1 012228 55 2 3/16 120 4 3/4 3 0.69 22-2 012303 100   165   4 1.873 22-3 012488 180   280   5 4 22-4 112478 200   205   7 4.01 22-5 012556 300   260   9 7.76

Kukko 22-4 Counterstay   Description The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3) The counter support nuts' friction resistance is reduced to a minimum as a result of the built-in pressure bearing (size 2 to 5). Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process. Mechanical pressure screw. Use For use with series 21, series 21-E or series 22-1-AS. Advantage The counter support can be combined with internal extractors and Kukko screw adapters. Almost all components available as replacement parts, time-saving order process thanks to numbering system.    Series 22   Art.Nr. EAN 4021176 Spannweite Gegenstütze mm Spannweite Gegenstütze inch Spanntiefe Gegenstütze mm Spanntiefe Gegenstütze inch Max. zulässige Belastung t Gewicht kg 22-1 012228 55 2 3/16 120 4 3/4 3 0.69 22-2 012303 100   165   4 1.873 22-3 012488 180   280   5 4 22-4 112478 200   205   7 4.01 22-5 012556 300   260   9 7.76

Kukko 22-5 Counterstay   Description The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3) The counter support nuts' friction resistance is reduced to a minimum as a result of the built-in pressure bearing (size 2 to 5). Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process. Mechanical pressure screw. Use For use with series 21, series 21-E or series 22-1-AS. Advantage The counter support can be combined with internal extractors and Kukko screw adapters. Almost all components available as replacement parts, time-saving order process thanks to numbering system.    Series 22   Art.Nr. EAN 4021176 Spannweite Gegenstütze mm Spannweite Gegenstütze inch Spanntiefe Gegenstütze mm Spanntiefe Gegenstütze inch Max. zulässige Belastung t Gewicht kg 22-1 012228 55 2 3/16 120 4 3/4 3 0.69 22-2 012303 100   165   4 1.873 22-3 012488 180   280   5 4 22-4 112478 200   205   7 4.01 22-5 012556 300   260   9 7.76

Kukko Internal extractor with slide hammer.

Kukko Extractor for parts with tapholes

Kukko Set of parallel-key and dowel-pin extractors DescriptionFor removing parts with centric threaded holes.Kukko thread inserts can be combined with counter supports and slide hammers.Instructions on the cover.Secure storage in special foam.Personal KUKKO-Chip-Code. UseFor extracting bushings and components with threads (dowel-pins, parallel-keys, bolts, etc.). AdvantagePractical package for universal use.Almost all components available as replacement parts, time-saving order process thanks to numbering system.Kit in the tried-and-tested KUKKO-i-Boxx-System.

Kukko Set of parallel-key and dowel-pin extractors

Kukko Internal extractor with slide hammer.

Kukko Set of bearing pulling and extracting tools

Kukko Set of bearing pulling and extracting tools

Kukko Set of bearing pulling and extracting tools

Kukko Set of bearing extracting tools

Kukko Set of bearing extracting tools

Kukko Set of bearing extracting tools

Kukko Set of bearing extracting tools DescriptionThe 2-shell design with extra large grasp edges ensures safe extraction.The internal extractors are equipped with an internal safety stop to protect against excess spreading and overloading.Mechanical pressure screw.Milled thread treated with special coating.Instructions on the cover.Secure storage in special foam. UseFor extracting inner bearings, bearing outer rings and bushings. AdvantagePractical package for universal use.KUKKO internal extractors can be combined with counter supports and slide hammers.The arms on the counter supports are easy-to-adjust thanks to an internal spring mechanism. (size 1 to 3)Thanks to their support struts, sizes (4 and 5) counter struts are particularly suited for large ball bearings, etc., and ensure that the assembly remains stable during the extraction process.Almost all components available as replacement parts, time-saving order process thanks to numbering system. How it worksPlace the internal extractor into the bearing´s hole.Using a ring spanner, tighten the nuts to open the jaws of the internal extractor. Make sure that the jaws sit securely below the bearing´s inner race.For removal, the spindle on the counter support series 22 or on the slide hammer series 22-0 is screwed onto the key spindle on the internal extractor.Counter support:2. The counter support´s arms must not block the part due to be removed. Make sure that the arms are parallel.3. Hold on to the T-grip and at the same time use the jaw wrench to tighten the nuts above the cross-beam until the component has been loosened from its position. Safety informationDo not use any electrical or pneumatic servo screwdrivers or hammer drills.Protective blanket required.Protective goggles required.
