Gedore 1.15/5 Puller 3-arm pattern 420x480 mm
€353.95
Content:
1 pcs
/ 5
Delivery time 5 working days
Variante
Product number:
107368
Manufacturer no.:
8006780
EAN:
4036976104691
Weight in kg:
8.9
Product information "Gedore 1.15/5 Puller 3-arm pattern 420x480 mm "
Gedore 1.15/5 Puller 3-arm 420x480 mm
Gedore 1.15/5 Puller 3-arm 420x480 mm
Features:
- Tried and tested
- particularly strong design for removing discs
- wheels
- ball bearings etc.
- With technical and economical benefits due to the variable clamping reach and automatic grip of the legs
- Particularly suitable for pulling off V-belt pulleys and flywheels which are mounted on longer shafts
- Upgradeable with hydraulic spindle
Technical features:
- Number of arms: 3
- Tractive force (max.) [t]: 12
- Hydraulic spindle optional: 1.06/HSP1
- Usable depth of hooked foot d2 [mm]: 20 mm
- Width across flats [mm]: 22 mm
- Thickness of hooked foot at tip: 3,5 mm
Gedore Code-Number: 8006780
EAN: 4036976104691
